HDMI to Fiber Extender
4K HDMI Video over fiber extender
PMD-4KHDMI-RS232-LC
1.Support resolution 4096*2160@30Hz max and backward compatible.
2.Support 1 channel bi-directional full-duplex RS232 (half-duplex RS485 optional).
3.Single-mode transmission distance up to 10Km, compatible with multimode up to 500meters.
4.Plug and play, no setting required.
2.Support 1 channel bi-directional full-duplex RS232 (half-duplex RS485 optional).
3.Single-mode transmission distance up to 10Km, compatible with multimode up to 500meters.
4.Plug and play, no setting required.
Features
1.HDMI video support maximum resolution 4096*2160@30Hz downward compatibility
2.Support international standard HDMI1.4 HDCP1.4;
3.EDID transparent transmission mode;
4.Support RGB&YCBCR4:4:4 YUV4:4:4 4:2:2 4:2:0;
5.Support DDC CEC HPD signal;
6.Support 1 channel bidirectional full-duplex RS232 (half-duplex RS485 optional);
7.Single-fiber/dual-fiber (optional)
8.Single/multi-mode compatibility, multi-mode transmission distance 1KM, single-mode transmission distance 10KM;
9.Delay < 2 ms;
10.Support hot swap signal, plug and play, no setting required.
Applicable for :
LCD splicing large screen, LED splicing screen, projection fusion program, video conference system;
Monitor testing and burn-in
Public Video System (Certification Companies, financial Markets, confidential documentary and etc)
High quality multimedia video conference display (Video Conference), briefing...
Municipal command center, substation control room, steel plant control room, cement plant control room, mine control room, coal mine, cement plant, thermal power station and fine chemical control room and digital machine room management.
Technical Indexes
1.HDMI video support maximum resolution 4096*2160@30Hz downward compatibility
2.Support international standard HDMI1.4 HDCP1.4;
3.EDID transparent transmission mode;
4.Support RGB&YCBCR4:4:4 YUV4:4:4 4:2:2 4:2:0;
5.Support DDC CEC HPD signal;
6.Support 1 channel bidirectional full-duplex RS232 (half-duplex RS485 optional);
7.Single-fiber/dual-fiber (optional)
8.Single/multi-mode compatibility, multi-mode transmission distance 1KM, single-mode transmission distance 10KM;
9.Delay < 2 ms;
10.Support hot swap signal, plug and play, no setting required.
Applicable for :
LCD splicing large screen, LED splicing screen, projection fusion program, video conference system;
Monitor testing and burn-in
Public Video System (Certification Companies, financial Markets, confidential documentary and etc)
High quality multimedia video conference display (Video Conference), briefing...
Municipal command center, substation control room, steel plant control room, cement plant control room, mine control room, coal mine, cement plant, thermal power station and fine chemical control room and digital machine room management.
Technical Indexes
Fiber index |
|
| Wavelength | 1310-1550nm |
| Rate | 10Gbps |
| Tx power | ＞-5db |
| Rx sensitivity | ＞-14db |
| Fiber connector | LC |
Video index |
|
| Video bandwidth | 10GHz Gbps |
| Resolution | 4096*2160@30Hz downward compatibility |
| Maximum pixel clock | 297MHZ |
| Effective cable length | 10M |
| Physical interface | HDMI female |
RS232 data index（3-wire system,full duplex）standard |
|
| Baud rate | 256000Hz downward compatibility |
| Data bits | 8 bits |
| Physical interface | 3-pin phoenix terminal |
RS485 data index（2-wire system,half duplex）optional |
|
| Error rate | <10^-9 |
| Bit rate | 0-400Kbps |
| Physical interface | 3-pin phoenix terminal |
Other index |
|
| Operating temperature | -20°C ~75°C |
| Storage temperature | -40°C ~85°C |
| Power supply | 12V1A |
| Power dissipation | ＜1.5W |
| Chassis | Aluminium alloy |
| Product net weight | 0.2kg/pcs |
| Product weight | 0.75kg/pair |
| Packing size | 275*220*55mm |
Package contents:
- 1x HDMI transmitter
- 1x HDMI receiver
- 1x SC/SC 3meters singlemode fiber patch cord
- 2 x power DC12V/1A(US/EU/UK/AU is available)
- 1 x User manual
- Online Service
-
