Features:

1. The item is 8 channels of HD-SDI over two single fiber optic cable with LC optical interface for remote video monitor,each optical cable transmission 4 channels HD-SDI separately. It is with one 10/100Mbps ethernet and one RS-422 data on the transmitter and receiver,HD-SDI signal with embedded audio signal.

2. Support cameras: HD-SDI (1.485Gbps). working distance: singlemode 0~20Km,compatible with multimode 0~300m.

3. The plug-and-play design makes the installation convenient and easy, the LED indicator design helps the user to know the working status easily, and there is no need for on-site adjustment.Fiber optical transmission excludes electromagnetic noise factor, it makes this product a perfect solution for efficient, reliable and secured HD-SDI signal transport.

4. It is widely used in TV live broadcast, high-definition video conferencing, high-definition video surveillance and other fields.

Function:

 8x HD-SDI

 1x 10/100Mbps Ethernet

 RS-422 data

 Double Optical interface, SFP module single LC

 Working distance: singlemode 0~20Km

Specification:

1.  Support resolution :1080P@30,25,24, 1080i@60,50,720P@60,50,30,25

2. The system support signals accord with standards of SMPTE292M,SMPTE259M,SMPTE297M,SMPTE310, SMPTE305 and support digital TV signals such as DVB-ASI meeting the industrial requirements of audio and video equipment with high performance and reliability.

3. The broadcast signal quality, fully compliant SMPT standard;

4. Optical interface: single LC (FC optional)

5. Data interface: RS-422 (RS485/232 optional)

6. The maximum cable length: SD 400m; HD 200M; 3G 140M;

7. Working distance: Single-mode 0-20Km, compatible with multimode 0~300m.

8. Singlemode 1310nm/1550nm

9. Voltage:AC100V~240V,DC5V/2A

10. Package: carton box

Package Include:

· 1 x 8CH HD-SDI Transmitter

· 1 x 8CH HD-SDI Receiver

· 1 x 3m LC/LC fiber optic patch cable

· 2 x Power adaptor AC100~240V DC5V/2A (default US, EU/UK/AU available )

· 1x Manual
