3G/HD SDI Converters
3G SDI Fiber Media Converter
HXT-3G-SDI-A-E
this unit can extend one 3G-SDI or HD-SDI Video/Audio/RS485/Ethernet signal over a fiber optic to far end, long transmission distance, Single-mode fiber can up to 12.4 Miles (20Km).
with two 3.125G SFP optical module, LC simplex port. HD-SDI signal is with embedded audio signal.
with two 3.125G SFP optical module, LC simplex port. HD-SDI signal is with embedded audio signal.
Function:
1 x 3G-SDI with loop out.
1 x 10/100Mbps Ethernet.
1 x 3.5mm Audio (Bi-directional).
2 x Audio (Bi-directional, RCA connector).
1 x RS-485 data (Reverse direction).
LC fiber connector, Singlemode fiber 0-20Km.
Feature
1. It can extend one 3G-SDI or HD-SDI Video/Audio signal over a fiber optic to far end, long transmission distance, Single-mode fiber can up to 12.4 Miles (20Km). with two 3.125G SFP optical module, LC simplex port. HD-SDI signal is with embedded audio signal.
2. Support SMPTE424M(3G-SDI), SMPTE292M(HD-SDI), SMPTE259M(SD-SDI) and DVB-ASI, Video resolution is compatible with 1080P@60/30/25, 1080i@60/50 59.94 and more.
3. With clock recovery, clock shaping, this function can make sure the video image no flicker, high quality design.
4. Support Video loop out function and reverse direction RS485 data, Supports embedded digital audio stream and 10/100Mps ethernet (RJ45 port) which can extend your networking signal through a fiber optic to far end up to 12.4miles, also can use for IP camera with RJ45 port and More.
5. Single-mode and multi-mode compatible, single-mode transmission distance up to 12.4Miles (20Km), multi-mode transmission distance up to 500M.
6. Tiny Delay <2ms, Real-Time Video Transmission for Exceptional Quality and Resolution
7. Plug and play, No need for on-site adjustment. Simply plug in BNC port and LC optical port, and it will work immediately.
Specification:
Working voltage:AC100V~240V,DC5V/2A(US/EU/UK/AU plug adapter optional)
Outer box size: 172x112x32mm (LxWxH)
Weight :1.2Kg per set.
Package: carton box
Package Include:
1 x 3G-SDI Transmitter
1 x 3G-SDI Receiver
1 x 3M LC-LC SM fiber patch cord
2 x External Power supply adapters (US/EU/UK/AU standard is optional)
1x User Manual
1 x 3G-SDI with loop out.
1 x 10/100Mbps Ethernet.
1 x 3.5mm Audio (Bi-directional).
2 x Audio (Bi-directional, RCA connector).
1 x RS-485 data (Reverse direction).
LC fiber connector, Singlemode fiber 0-20Km.
Feature
1. It can extend one 3G-SDI or HD-SDI Video/Audio signal over a fiber optic to far end, long transmission distance, Single-mode fiber can up to 12.4 Miles (20Km). with two 3.125G SFP optical module, LC simplex port. HD-SDI signal is with embedded audio signal.
2. Support SMPTE424M(3G-SDI), SMPTE292M(HD-SDI), SMPTE259M(SD-SDI) and DVB-ASI, Video resolution is compatible with 1080P@60/30/25, 1080i@60/50 59.94 and more.
3. With clock recovery, clock shaping, this function can make sure the video image no flicker, high quality design.
4. Support Video loop out function and reverse direction RS485 data, Supports embedded digital audio stream and 10/100Mps ethernet (RJ45 port) which can extend your networking signal through a fiber optic to far end up to 12.4miles, also can use for IP camera with RJ45 port and More.
5. Single-mode and multi-mode compatible, single-mode transmission distance up to 12.4Miles (20Km), multi-mode transmission distance up to 500M.
6. Tiny Delay <2ms, Real-Time Video Transmission for Exceptional Quality and Resolution
7. Plug and play, No need for on-site adjustment. Simply plug in BNC port and LC optical port, and it will work immediately.
Specification:
Working voltage:AC100V~240V,DC5V/2A(US/EU/UK/AU plug adapter optional)
Outer box size: 172x112x32mm (LxWxH)
Weight :1.2Kg per set.
Package: carton box
Package Include:
1 x 3G-SDI Transmitter
1 x 3G-SDI Receiver
1 x 3M LC-LC SM fiber patch cord
2 x External Power supply adapters (US/EU/UK/AU standard is optional)
1x User Manual
