Features:

1. Extend 1080P HDMI Video/Audio signal through an optical fiber cable, Long-distance
transmission up to 20km(12.4miles). compatible with multimode up to 500meters. Uncompressed transmission, with no Latency. You can see the video or talk to others fluently.


2. With KVM function, you can remote control PC by USB Mouse and Keyboard. With Bi-directional 3.5mm stereo audio, you can do real-time intercom with others on the other side far away, and with RS-232 data. you can control the rs232 serial device from remote side.
Note: The USB port only for Keyboard and Mouse, don't support USB Disk, USB hub, USB dongle etc.

3. Video Resolution up to 1080@60Hz, Compatible backwards. Built-in automatic equalization system, the picture is smooth, clear and stable. Built-in ESD electrostatic protection circuit, all-round protection system safety.

4. Widely used in various large-scale multimedia high-definition displays, information release and news centers, traffic guidance and information display systems, outdoor large-screen display systems, large-scale stage display and entertainment centers, live TV, multimedia conferences, military command and exercises, etc. Multiple fields.

5. Very easy to operate, Plug and play, No need to set up.







Note: The USB port only for Keyboard and Mouse, don't support USB Disk, USB hub, USB dongle etc.


Specifications

• Connector: HDMI female
• HDMI Cable Range: <16.5ft (5 Meters)
• Support HDMI version: 1.2
• Fiber type: FC
• Applicable fiber: universal single-mode and multi-mode.
• Working distance: Single-mode 0-20Km.Multimode:0-500meters.
• Audio Interface: 3.5MM external stereo audio, Bidirectional
• Support audio format: DTS-HD/Dolby-true HD/LPCM7.1/DTS/Dolby-AC3/DSD
• RS232 Baud rate: Backward Self-adaptive, Max：115200bps
• USB interface: USB1.0
• Power input: AC100-240V, DC5V2A (US/EU/UK/AU plug is available.)
• Dimensions: 155x103x31mm(HxWxH)


Package:

• HDMI Transmitter x1
• HDMI Receiver x1
• External Power adapter x2
• User Manual
